NGXBK01, ZERO U MOUNTING BRACKET 3 SLOT NGX UNLOADED
NGXBK01
ZERO U MOUNTING BRACKET 3 SLOT NGX UNLOADED
SPEDIZIONE GRATUITA
Certificati
Introduction
The Zero U Panel adds an additional patch panel location to free up extra space in the cabinet.
The zero U panel is installed vertically in the cabinet rail and creates a convenient point for distribution of patch cables within the vertical racking system.
The Zero RU bracket accepts up to 3 Nexconec NGX modules.
The Bracket is supplied unloaded and the modules are supplied separately.
Features and Benefits
- Zero RU Mounting
- 3 Slots NGX (Up to 72FO in LC)
- Modular with MPO, Patching, Transition or Patching modules
- Datacentre & Enterprise network
- Indoor application
- Accepts Indoor and Outdoor Pre-terminated cables and MTP trunks and Splicing
Specifications
| Mounting Type | Vertical Left and right rack mounting |
|---|---|
| Housing Color | Black |
| Application | Indoor IP20 |
| Lockable | No |
| Dimensions (W x D x H in MM) | 74.1 x 142.5 x 222 |
| Net Weight | 0.3KG |
| Access Type | Front access and rear access |
| Cable Entry Direction | Rear |
| Cable Management | Vertical up and down cable managers |
| Slot Type | NGX |
| Number of Slots | 3 |
| Fiber Capacity | 72 in LC / 36 in SC |
