DN-95323-1
SWITCH 8 PORTE FAST ETHERNET POE 120 WATT CON 2 PORTE UPLINK
Bisogno di aiuto?
Description
Fast Ethernet PoE Switch 8-port PoE + 2-port uplink, 120W PoE budget
Network Switch with integrated Power over Ethernet (PoE) solution for an optimal, cost effective and fast integration in small or medium-sized networks
- 8-port 10/100Base-TX with PoE support
- 2-port Fast Ethernet uplink
- Meets the network standards IEEE 802.3, IEEE802.3u, IEEE802.3q, IEEE802.3az, IEEE802.3x, IEEE802.3af, IEEE802.3at
- The VLAN mode provides a port-based VLAN function that prevents multicast or broadcast requests from interfering with each other
- The Extensive mode offers range extension of up to 250 m at 10 Mbps
- Maximum PoE power of 120 watts
Fast Ethernet PoE Switch,8-port PoE + 2-port uplink, 120W PoE budget
Technical Details
- 8-port 10/100Base-TX with PoE support
- 2-port Fast Ethernet uplink
- Meets the network standards IEEE 802.3, IEEE802.3u, IEEE802.3q, IEEE802.3az, IEEE802.3x, IEEE802.3af, IEEE802.3at
- With integrated DIP switch to enable VLAN or extensive mode
- Extensive mode for ranges up to 250 meters with a transmission rate of 10Mbps
- PoE current output 55 V DC, max. 30 W per port
- PoE power supply mode A, PIN 1/2(+), 3/6(-)
- Supports non-blocking, non-head-of-line forwarding
- Supports back pressure and bandwidth control in each port
- Store and forward technology for optimized data transfer
- Automatic speed and half/full duplex recognition/adjustment
- Auto MDI/MDI-X function
- Backplane with 2 Gbps
- Supports up to 8K MAC addresses
- Integrated power supply unit
- Maximum PoE power of 120 watts
- Maximum output line 125 watts
- Fanless design
- Ethernet speed: Fast Ethernet
- Industrial usage: no
- Numero di porte: 8
- PoE (Power over Ethernet): yes
- Protection against vanadlism: no
- Managed: no
- Installation type: 19 inch, Desktop
- Outdoorsuitable: no
- Number of ports (Uplink): 2
- Uplink port connection: RJ45/SFP
- VLAN: no
- PoE Power budget: 120 W
- PoE standard: IEEE802.3at (PoE+)
