FMWB48DXKX-21AD
Scatola a muro con serratura W04 - E2000 Singlemode APC - 4 adattatori
Description
The W21 wall box system can be supplied unloaded ready for the installer to load with their choice of adapters, or pre-loaded with adapters ready for installation. With the ability to use a full array of adapter types, this wall box offers a flexible solution to the end user, enabling them to incorporate a multifunctional wall mounted box which allows easy access during installation or rework with no disturbance of existing cable or fibers. In addition to the array of adapters, the box also offers multiple cable entry and exit solutions: up to 8 standard entry points for loose tube, tight buffered, pre-terminated, steel tape armoured cable and 2 slotted positions for patch cord exit.
Features and Benefits
- Up to 48 fiber
- Multiple adapter options
- 48 adapter positions
- RoHS, REACH, SvHC
- Available in single door and double door versions
- Internal bend radius protection included
Applications
Internal applications
For use in multi dwelling units or demarcation points within a network
Data centers or telecommunication networks
Specifications
Height: 360 mm
Width: 360 mm
Depth: 122 mm
Net Weight: 7.5 kg
Packaged Weigh:t 7.8 kg
Package Dimensions: 420mm (W) x 400mm (D) x 130mm (H)
IP Rating: IP 20
Suitable for adapter type: ST / FC
Number of doors: 2
Cable entry: 4 x 20 mm 4 x 25 mm
Material: Cold Rolled Steel
Material thickness: 1.2mm
Material coating: Electro Static Powder Coating
Colour: Grey RAL 7035
Operating temperature: -40°C to + 60°C
Materials compliant to: RoHS, Reach, SVHC
Designed in accordance with: TIA/EIA 568.C, ISO/IEC 11801, EN 50173, IEC 60304, IEC 61754, EN 297-1
