GS-4210-8T2S Planet Managed

 A Perfect Managed Edge Switch with Advanced L2/L4 Switching and Security

PLANET GS-4210-8T2S is an 8-Port Gigabit Managed Ethernet Switch with SFP interfaces specially designed to build a full Gigabit backbone to reliably transmit and forward data to remote network through fiber optic. It provides 8 10/100/1000BASE-T copper ports and 2 extra 100/1000BASE-X SFP fiber optic interfaces with built-in power system. Besides support for 20Gbps switch fabric to handle extremely large amounts of video, voice and important data in a secure topology, the GS-4210-8T2S provides user-friendly but advanced IPv6 / IPv4 management interfaces and abundant L2 / L4 switching functions. It is the best investment for businesses and SOHOs expanding or upgrading their network infrastructures.

Applications

Department/Edge Security and QoS Switches for SMBs

The GS-4210-8T2S connects up to 10 high-speed workstations in the Ethernet environment, in which its two SFP mini-GBIC interfaces uplink to a department backbone. Moreover, the Switch provides 20 Gigabit per second switch fabric and high bandwidth for backbone connection. The GS-4210-8T2S improves the network efficiency and protects the network clients with the following powerful features:

• 　IPv6/IPv4 dual stack management
• 　Layer 2 to Layer 4 security and QoS
• 　802.1x Port-based network access authentication security
• 　IPv4 Multicast IGMP and IPv6 MLD Snooping

The advanced functionality of the GS-4210-8T2S eliminates traditional issues associated with the use of Ethernet. Users can be separated with advanced VLAN functionality to enhance security. It makes the GS-4210-8T2S one of the best and most cost-effective switch solutions for SMBs.

Features and Benefits

Physical Port

8 10/100/1000BASE-T Gigabit RJ45 copper ports
2 100/1000BASE-X SFP ports
RJ45 console interface for switch basic management and setup

Hardware Specifications

Copper Ports: 8 x 10/100/1000BASE-T RJ45 Auto-MDI/MDI-X ports
SFP Ports
 2 x 100/1000BASE-X SFP interfaces
 Supports 100/1000Mbps dual mode and DDM
Console: 1 x RS-232-to-RJ45 serial port (115200, 8, N, 1)
Reset Button:
 < 5 sec: System reboot
 > 5 sec: Factory default
Dimensions (W x D x H): 280 x 180 x 44 mm, 1U height
Weight: 1315g
Enclosure: Metal
Power Requirements: AC 100~240V, 50/60Hz, 2.5A, auto-sensing
Power Consumption/ Dissipation: 6.8 watts/ 23.2 BTU
ESD Protection:
 Contact Discharge 6KV DC
 Air Discharge 8KV DC
Fan: Fanless design

LED System:
　PWR x1 (Green)
　SYS x1 (Green)
Per PoE Port (Port 1 to Port 8):
　LNK/ACT x1 (Green)
Per Gigabit SFP Port (Port 9 to Port 10):
　100/1000 LNK/ACT x1 (Green)
