IDLV-25-12 Mean Well AC DC Driver Led

 Features

• Constant Voltage PWM style output
• with frequency 1KHZ
• Plastic housing with class ll design
• BUl|t-ll'l active PFC function
• No load power consumption<O.5W(Blank-Type)
• Function options: 2 in 1 dimming (dim-to-off); Auxiliary DC output
• 3 years warranty

Applications

1. LED strip lighting
2. Indoor LED lighting
3. LED decorative lighting
4. LED architecture fighting

Description

IDLV-25 series is a 25W AC/DC LED driver featuring the constant voltage mode PWM style output
design. IDLV-25 operates from 90~295VAC and offers models with different rated voltage ranging
between 12V and 60V. Thanks to the high efficiency up to 84%, with the fanless design, the entire
series is able to operate for -20°C~+90°C case temperature under free air convection. IDLV-25 is
equipped with various function options, such as dimming methodologies, so as to provide the design
flexibility for LED lighting system.

Specfications

OUTPUT

DC VOLTAGE: 12v
RATED CURRENT: 1.8A
RATED POWER: 21.8w
DIMMING RANGE: 0~100%
VOLTAGE TOLERANCE: ±10.0%
PWM FREQUENCY (Typ.): 1KHz (120%)
SETUP TIME: 500ms / 230VAC 1200ms/115VAC
AUXILIARY DC OUTPUT: Nominal 12V(deviation 11.4~12.6)@50mAforA-Type only

INPUT

VOLTAGE RANGE: 90 ~ 295VAC
EFFICIENCY (Typ.): 80%
AC CURRENT (Typ.): 0.4A/115VAC   0.16A/ 23OVAC   0.13A/ 277VAC
