LDD-1500L, DC/DC Driver LED Constant Current (CC) 45W Input 6-36Vdc Output 2-30Vdc 1500mA wire style
LDD-1500L
DC/DC Driver LED Constant Current (CC) 45W Input 6-36Vdc Output 2-30Vdc 1500mA wire style
Bisogno di aiuto?
Features
- DC/DC step-down converter
- Constant current output: 1000mA to 1500mA
- Wide input voltage: 6 ~ 36VDC
- Wide output LED string voltage: 2 ~ 30VDC
- High efficiency up to 95%
- Built-in EMI filter, comply with EN55015 and FCC part15 without
- additional input filter and capacitors
- Built-in PWM +analog dimming and remote ON/OFF control
- Protections: Short circuit
- Cooling by free air convection
- Fully encapsulated with IP67 level for pin and wire style
- Non-potted, optional conformal coating for SMD style
- (Order No.: LDD-1000 LSC)
- Compact size
- Low cost, high reliability
- Suitable for driving illumination LED
- 3 years warranty
Specifications
OUTPUT
CURRENT RANGE: 1500mA
VOLTAGE RANGE: 2 ~ 30VDC
CURRENT ACCURACY (Typ.): ±5% at 24VDC input
RIPPLE & NOISE (max.): 1.5Vp-p
SWITCHING FREQENCY: 1000KHz
EXTERNAL CAPACITANCE LOAD (max.): 2.2uF
INPUT
VOLTAGE RANGE: 6 ~ 36VDC
EFFICIENCY(max.): 95% at full load and 24VDC/36VDC input
DC CURRENT:
Full load: 1450mA
No load: 5mA
FILTER: Capacitor
