NTS-400P-224 Mean Well Onda Pura

Features

• Compact size and light weight
• True sine wave output (THD<3%)
• High surge power up to 800W
• 250W convection, 400W forced air
• AC output voltage and frequency selectable by DIP S.W
• No load disspation <1.5W max. at standby saving mode
• -20°C ~ +70°C wide operating temperature
• Power ON-OFF remote control
• Front panel indicator for operation status
• Protections:
•         Input: Reverse polarity/ DC low alarm / DC low shutdown / Over voltage
•         Output: Short circuit / Overload / Over temp.
• Battery over discharge protection(Low voltage disconnect)
• Suitable for lead-acid or li-ion batteries
• Support Tx/ Rx for monitoring power inverter status
• Conformal coating
• 3 years warranty

Applications

• Mobile device
• Home and office appliance
• Power tools
• Portable equipment
• Vehicle
• Yacht
• Off-grid solar power system
• Wireless network
• Telecom or datacom system

Description

NTS-400P is a 400W highly reliable built-in type off-grid true sine wave DC-AC power inverter. Its key features include: digital design with MCU control, streamlined control circuitry that quickly responds to environmental changes and improves reliability, compact size, light weight, 800W peak power, adjustable AC output voltage and frequency, -20~+70°C wide operating temperature range, built-in remote ON/OFF control, low no-load power consumption (energy saving mode < 1.5W max.), complete protection features, and etc. Combined with batteries, the NTS-400P is suitable for use in residential, commercial, marine, automobile, and remote areas with no access to utility power, and the output can be used to power fans, TV, radio, phone charger, PC/laptop, lighting, outdoor camping equipment, marine AC power, and etc.

Specifications

AC OUTPUT

RATED POWER(Continuous): 400W
OVER RATED POWER(3 Min.): 460W
PEAK POWER(10 Sec.): 600W
SURGE POWER(30 Cycles): 800W
AC VOLTAGE:
    Default setting set at 230VAC
    200 / 220 / 230 / 24OVac selectable by DIP S.W
FREQUENCY:
    Default setting set at 50Hz±0.1Hz
    50/60Hz selectable by DIP S.W
WAVEFORM: True sine wave (THD<3%)
AC REGULATION: ±3.0% at rated input voltage

DC INPUT

DC VOLTAGE: 24V
VOLTAGE RANGE (Typ.): 20 ~ 33Vdc
DC CURRENT (Typ.): 20A
No LOAD DISSPATION (Typ.):
    NON-SAVING MODE: 10w
    SAVING MODE: Default disable, ≤1.2W ~ 1.5W by models @ auto detec AC outp ut load ≤10W will be changed to saving mode
                1.3W
OFF MODE CURRENT DRAW: ≤1mA
EFFICIENCY:(Typ.): 93%
BATTERY TYPES: Lead Acid or li-ion
