NVR-915 Planet Video Recorder

NVR-915 Planet

NVR-915

9-Ch Network Video Recorder

Clicca per maggiori dettagli

Q.tà':

Articoli Prezzo (IVA esc.)
1+ pz.€ 392,69

Prezzo di 1 pz. iva (22%) inclusa: € 479,08

Disponibilità: 10 gg lav

  >> I tempi protrebbero essere piĆ¹ lunghi da quelli indicati <<

Brand: PLANET

SKU: 115708

Model: NVR-915

 Efficient SMB Surveillance Solution

PLANET NVR-915 is a 9-channel Linux embedded network video recorder (NVR) for restaurants, retail stores, stockrooms and more. The NVR-915 supports IP cameras with up to 5 megapixels and H.264 video codec for high-quality real-time monitoring, recording and playback. It also supports high-resolution video quality on any HD monitor. With two internal 4TB SATA III hard disks and e-SATA interface, it provides you with more storage capacity and keeps video files in the NVR for a long period of time. Once the NVR-915, armed with a complete surveillance equipment, detects any suspicious events, you will be alerted with alarm via email; FTP, HTTP and TCP servers; and more. The NVR-915 is thus able to further enhance security within the premises to protect your property. Moreover, it is fully compatible with mobile app and Internet Explorer on Windows operating system for multi-platform remote access.

Specifications

Hardware
Ethernet: 1 x RJ-45, 10/100/1000Base-T
USB Interface: 2 x USB 2.0 for backup device and mouse
Video Interface: VGA and HDMI video interfaces
Audio Interface: 1 x mic-in (phone jack 3.5mm), 1 x audio-out (phone jack 3.5mm)
Storage Device: 2 x 3.5" SATA III hard disk connector, 1 x e-SATA connector
LED: Power, HDD, LAN, REC, Event, Alarm, Camera, DI/DO
Button: Reset
Buzzer: 1 x Buzzer
DI/DO: 4 x Digital in, 4 x Digital out
Camera:
Max. Channels: 9-channel IP cameras
Camera Added: Manual / Auto Search / Auto Setup
Video:
Compression: H.264
Resolution: 5M / 3M / Full HD / SXGA / VGA / QVGA
Max. Live Video Frame Rate (Local Display): 480fps@D130
360fps@720P30
120fps@1080P30
20fps@5M15
Max. 5MP/channel
Max. Throughput: 48Mbps
Snapshot: Preview snapshot in HDD or removable device
Search event snapshot
Backup to USB device
Audio:
Audio Type: 2-way
Audio Format: G.711, G.726
Live View:
Display Mode: Live View / Playback / Full Screen
Split Screen: 1 / 4 / 6 / 9 / Full Screen
Full Screen: 1 / 4 / 6 / 9
PTZ Support: Preset / Tour / Auto Pan / Iris / Focus / Speed and Joystick
Playback:
Split Screen: 1 / 4 / 6 / 9 / Full Screen
Search Mode: Simple / Graphical / Event
Play Method: Play / Reverse / Pause / Seek / Pre I-frame / Next Frame
Search by time or event
Record:
Recording Mode: Scheduled recording each camera
Round the Clock / Motion Record mode / DI Detection / Event Triggering
Pre-alarm / Post-alarm configuration
Auto Recycle
Monitor:
Dual Monitor: Displays the same contents, depending on max. channels
Monitor Resolutions: 1920x1080, 1440x900, 1366x768, 1280x1024, 1024x768
Network and Configuration:
Network Service: Fixes IP / DHCP / PPPOE / DIPS Report / UPNP / DDNS
Notification: SMTP / HTTP / FTP / TCP
Triggers and Event:
Event Type: Motion Alarm
Alarm Disconnection
Detection
Digital Input
Scheduled Triggering
HDD Error
Event Action: Display on Screen
DO
Alarm
Snapshot
Recording
Mail
FTP
TCP
HTTP
Management:
Number of Groups: 2 (Administrator and User )
Privileges: Live View / Playback / Record / Setting / PTZ / Two-way Audio
User Interface: Graphic local user interface (operated by mouse)
Web browser (Internet Explorer 7 or above)
CMS Utility
Log Type: System / Event / Bit-rate
Software Utility: Search utility / Mobile app / CMS
Environment:
Power: 12V DC, 4.16A
Consumption: 8W (without HDD)
Operating Temperature: 0~40 degrees C
Storage Temperature: -40~70 degrees C
Humidity: 0~85% (non-condensing)
Weight: 1455g
Dimensions (W x D x H): 330 x 252 x 57 mm
