DIN100W24, Power supply, DIN rail, 100 W, 24 V, 4.15 A
DIN100W24
Power supply, DIN rail, 100 W, 24 V, 4.15 A
Bisogno di aiuto?
Description
The new DIN rail switching power supplies of the DIN series from POS-Power are characterized by their high reliability and stability. The switched-mode power supplies can also be easily accommodated in control cabinets of small sizes and supply the consumers efficiently and reliably with the necessary energy. Mounting is quick and easy using the click system on all standard DIN rails. The range of functions is rounded off by the protective devices (short circuit, overload, overvoltage, overheating) and a DC-OK signal.
Features
Power: 99.6 W
Output voltage: 24 V DC (adjustable 21.6 - 28 V)
Output current: 0 - 4.15 A
low residual ripple: 360 mVpp
Efficiency: 88%
Inrush current: max. 40 A
Universal input: 180 - 264 V AC
Type: constant voltage power supply
Isolation class II
can be mounted directly onto the DIN rail (all common DIN rails such as TS-35/7.5 or 15)
closed design, touch-protected screw connections
fanless convection cooling
Overload protection through current limitation, auto recovery
Protective devices against short circuit, overload, overvoltage, overheating
LED display and DC OK signal
low no-load power
operating temperature range: -20 ... +50 °C
Dimensions / Weight: 100 x 93 x 56 mm / 310 g
Specifications
General
Type: Switching power supply
Temperatur max.: -20 … +50
Design: Rail mounting
Electrical values
Output voltage: 24 V DC
Current: 4.15
Performance: 99.6 W
Efficiency: 88 %
Making current: 40 A
Ripple: 360 mV
Implementation
Cable cross-section: Hutschiene, 15 mm²
Mounting: DIN rail
Specials
Short circuit protected: Yes
Overload protection: Yes
Packaging
Packaging: Individual packaging
Measures
Width: 100 mm
Height: 93 mm
Depth: 56 mm
Manufacturer specifications
Manufacturer: POS POWER
Factory number: DIN100W24
Package weight: 0.326 kg
RoHS: conform
