DN-81210, Mini GBIC Copper SFP Module, 10 Gbps, RJ45
DN-81210
Mini GBIC Copper SFP Module, 10 Gbps, RJ45
SPEDIZIONE GRATUITA
Bisogno di aiuto?
Descrizione
10 Gigabit Ethernet over CAT 6A cable
- Compatible with IEEE 802.3 standard and most common switch vendors
- Hot-pluggable SFP footprint
- Distance: Up to 100 m (1 Gbit)
- High operating temperature: 0°C to 65°C
- Easy plug-and-play installation
The DIGITUS® 10G Mini GBIC SFP transceiver modules offer the highest quality and reliability. The modules offer a perfect opportunity for you to extend your Gigabit network switch with an additional RJ45 connection. Thanks to the hot-plug capability, you can install the module without any interruption of the network traffic or restart of the device. In addition, conformity with the MSA (Multi Source Agreement) standard provides compatibility with the current network switch manufacturers. It is compatible with the 10GBase-T / 5GBase-T /2.5GBase-T / 1000Base-T standards as specified in IEEE 802.3.
Dettagli tecnici
- Data transfer rate: 10 Gigabit max. (IEEE802.3 compatible)
- Compatible standards: 10GBase-T, 5GBase-T, 2.5GBase-T, 1000Base-T
- Cable length: 1000Base-T: 100 m, 5 / 2.5GBase-T: 50 m, 10GBase-T: 30 m
- MSA (Multi Source Agreement) compliant
- Hot pluggable - installation possible while in operation
- Auto MDI/MDI-X
- Operating temperature: 0°C to 65°C
- Storage temperature: -40°C to 85°C
- Serial communication protocol: I²C clock rate: 200 Hz
- Broadcasting Mode: Unidirectional
- Manufacturer compatibility: Universal (MSA)
- Connector: RJ45
- DDM Support: no
- Distance (km): 0.1
- Mode: Copper
- Ethernet speed: 10 Gigabit
