M-1800, 8DI, sink, 24VDC, RTB
M-1800
8DI, sink, 24VDC, RTB
SPEDIZIONE GRATUITA
Bisogno di aiuto?
Prodotti Correlati
Certificati
Features
- 8 digital inputs, sink, 24 VDC
Specifications
Digital Inputs: 8 channels, sink type
On-state Voltage: 24 VDC nominal, min. 11 VDC to max. 28.8 VDC
Min. Off-state Voltage: Max. 5 VDC
On-state Current: Max. 6 mA/point @ 28.8 VDC
Input Impedance: Typ. 5.1K ohms
Filtering Time: Typ. 1.5 ms
Common Type: External common (single common)
Power Consumption: 35 mA @ 5 VDC
